Viewing the virtual disk information gives a wealth of information including the RAID type, Cache mode, Size, Name, etc./perccli /c0/v0 show Viewing virtual disk information with PERCCLI utility If we want to see the individual disks information, we can do that as well./perccli /c0/d0 show Viewing disk information with PERCCLI Dell RAID utility

If we simply want to see the count of controllers installed in the system, we can use the below./perccli show ctrlcount Viewing available controllers with PERCCLI perccli show Checking controller availability with PERCCLI We can list the Dell PERC RAID controller itself, check availability, number of controllers etc. To run the command make sure you are changed to the /opt/lsi/perccli directory./perccli Listing the available PERCCLI commands To see all the commands and parameters available, we can simply run the. Now that we have the PERCCLI utility installed on our VMware ESXi host, let’s take a look at the available commands and how we can manage Dell RAID in VMware ESXi 6.5 with PERCCLI.

#Dell perc h200 vmware esxi install#

esxcli software vib install -v /tmp/.vib -no-sig-check Use esxcli command to install the vib file copied over Manage Dell RAID in VMware ESXi 6.5 with PERCCLI

As soon as the install is finished, we are ready to manage RAID. Again, it is extremely useful to know we do not have to maintenance mode the host or reboot to instantiate the PERCCLI utility. Use SCP utility to copy over the PERCCLI vib fileĪs with the Avago/LSI StorCLI utility, as you see below, when installing the PERCCLI utility, we are not required to reboot. I like to copy these types of installs over to the /tmp folder for a temporary landing spot for the installation file.

#Dell perc h200 vmware esxi download#

Download PERCCLI utility from Dell Support siteĪfter using 7-zip or another utility to extract the tar.gz file, copy over the resulting .vib file to your VMware ESXi host. To obtain the PERCCLI utility, simply plug in your service tag on the Dell Support site, and select either VMware 6.0 or VMware 6.5 for the operating system. The process to install Dell PERCCLI Utility in VMware ESXi 6.5 is the same as installing the Avago/LSI StorCLI, however, below is a quick run through of installing the PERCLI on a 14G Dell PowerEdge R740 running VMware ESXi 6.5 U1. Install Dell PERCCLI Utility in VMware ESXi 6.5

#Dell perc h200 vmware esxi how to#

In this post we will walk through how to install and manage Dell RAID in VMware ESXi 6.5 with PERCCLI utility. In working recently with a new 14G PowerEdge R740 server loaded with ESXi 6.5 running a DAS setup, I was able to pull down the PERCCLI utility for ESXi 6.5 and install on the host to manage RAID. If you are not already aware, Dell maintains a customized version of the StorCLI utility called PERCCLI that is available for downloaded with compatible systems. However, the vanilla StorCLI utility may not work, especially with 14G servers with the newest PERC adapters installed. If you run a Dell PowerEdge server with a PERC adapter as most know, these are based on Avago/LSI adapters. The advantage of loading/using the Avago/LSI StorCLI utility is we don’t have to reboot the host to start using it as the VIB install doesn’t require a reboot.

#Dell perc h200 vmware esxi driver#

Have you confirmed that the H200 has Boot Support set to BIOS and OS? Have you also installed the card's driver for the OS of choice? Make sure the Preferred Boot device is selected as well (as per this link).We have covered the Avago/LSI StorCLI in past posts and how extremely useful it can be loaded on ESXi servers that have DAS volumes being presented with an Avago/LSI RAID controller. Something else to try is to check your H200 settings. Not to suggest it is broken but just that it has something to do with why you can't install the OS. If you're able to boot from install DVD with your HDD connected directly to the board, that would point to the H200 as the place to focus. Just to test and see if that may be the problem, have you tried to connect your drives directly to the SATA ports on the board? This is my setup with all SATA ports set to AUTO. The only difference between your setup and mine that I can tell is that you've got the H200 with RAID1. To be honest it sounds like you've tried these options already to no avail. Then with OS DVD inserted, I made sure to select the DVD drive during boot and the OS installed from DVD to my SSD.Since I don't have RAID but I do have 2 drives, I had to make sure that my OS disk was selected here and not my data disk The second boot device is my OS drive.Go to the Boot Settings then access Set Boot Order.Make sure you have BIOS selected for Boot Mode and that the DVD drive is the first boot device, followed by the hard drive.
